Novastar MCTRL660 Pro LED Display Controller

News Shopping Technology

The MCTRL660 PRO is a professional controller developed by NovaStar. A single Novastar MCTRL660 PRO has a loading capacity of up to 1920×1200@60Hz. It supports custom resolutions with the width up to 3840 pixels and height up to 2560 pixels, which meets configuration requirement of ultra-large screens.

The MCTRL660 PRO has a variety of video connectors:

  • Input connectors: 1 × 3G-SDI, 1 × HDMI 1.4a, 1 × single-link DVI
  • Output connectors: 6 × Gigabit Ethernet port, 2 × 10G optical port
  • Loop output connectors: 1 × 3G-SDI LOOP, 1 × HDMI 1.4a LOOP, 1 × DVI LOOP by Novastar
  • The MCTRL660 PRO has many industry-leading advanced technologies:
  • Input of ultra-high color depths: 10-bit/12-bit RGB 4:4:4/YCbCr 4:4:4, with input resolutions up to 1920×1080@60Hz, increasing color expression capabilities by 4096 times compared to 8-bit inputs, and presenting images with rich and delicate colors same as Novastar TB6, smoother transitions, as well as clearer details
  • Supports individual Gamma adjustment for RGB when the color depth of input source is 10-bit or 12-bit, which effectively controls image non-uniformity under low grayscale and white balance offset to improve image quality.
  • Low latency: Less than 1 ms (when the start position of image is 0.)
  • Dual working modes: working as sending card and fiber converter
  • One-click backup and recovery, quickly recovering previous screen configurations to deal with sudden on-site failure
  • Image mirroring, allowing for more cool and dazzling stage effects
  • Auto LED screen configuration
  • Web control
  • Pixel level brightness and chroma calibration
  • Monitoring of inputs
  • Multiple MCTRL660 PRO units can be cascaded.

The MCTRL660 PRO is mainly used for the rental and fixed fields, such as concerts, live events, security monitoring centers, Olympic Games and various sports centers.

Video Source Features



Input Connector

Features

Color Depth

Sampling Format

Maximum Input Resolution



HDMI 1.4a

8-bit

RGB 4:4:4

YCbCr 4:4:4

YCbCr 4:2:2

YCbCr 4:2:0

1920×1200@60Hz

10-bit/12-bit

1920×1080@60Hz



Single-link DVI

8-bit

1920×1200@60Hz

10-bit/12-bit

1920×1080@60Hz





3G-SDI

Maximum supported input resolution: 1920×1080@60Hz. Note:

l 3G-SDI input sources do not support input resolution and color depth settings.

l The Gamma value can be adjusted for 8-bit input sources and cannot be adjusted for 10-bit or 12-bit input sources.

Front Panel

No.

Description

1

Operating indicator

Green: The device is running normally.

Red: The device is in standby mode.

2

Standby button

3

OLED operation screen

4

Function knob

5

BACK button: Press to go back to the previous menu.

6

INPUT button: Press to choose a video source.

7

USB port: Used to update firmware

Rear Panel

Connector

Connector Name

Description







































Input

















DVI IN

Single-link DVI connector

  • Custom resolutions supported: Maximum width: 3840 pixels Maximum height: 2560 pixels
  • Supported standard resolutions: 1024×768@(24/30/48/50/60/72/75/85/100/120)Hz 1280×1024@(24/30/48/50/60/72/75/85)Hz 1366×768@(24/30/48/50/60/72/75/85/100)Hz 1440×900@(24/30/48/50/60/72/75/85)Hz 1600×1200@(24/30/48/50/60)Hz 1920×1080@(24/30/48/50/60)Hz 1920×1200@(24/30/48/50/60)Hz 2560×960@(24/30/48/50)Hz
    2560×1600@(24/30)Hz

















HDMI IN

HDMI 1.4a compliant

  • HDCP 1.4 compliant
  • Custom resolutions supported: Maximum width: 3840 pixels Maximum height: 2560 pixels
  • Supported standard resolutions: 1024×768@(24/30/48/50/60/72/75/85/100/120)Hz 1280×1024@(24/30/48/50/60/72/75/85)Hz 1366×768@(24/30/48/50/60/72/75/85/100)Hz 1440×900@(24/30/48/50/60/72/75/85)Hz 1600×1200@(24/30/48/50/60)Hz 1920×1080@(24/30/48/50/60)Hz 1920×1200@(24/30/48/50/60)Hz 2560×960@(24/30/48/50)Hz
    2560×1600@(24/30)Hz





3G-SDI IN

  • SMPTE ST 425-1 Level A & B, SMPTE ST 274, ST 296, ST 295 compliant
  • Maximum supported input resolution: 1920×1080@60Hz

Note: 3G-SDI input sources do not support input resolution and color depth settings.





Output





RJ45 × 6
OPT1 OPT2

  • 6 Gigabit Ethernet ports
  • Maximum loading capacity of a single Ethernet port:

−       For 8-bit input sources: 650,000 pixels

−       For 10-bit/12-bit input sources: 320,000 pixels

  • Support redundancy between Ethernet ports.
  • 10G optical ports
    • Single-mode twin-core fiber: Support LC optical connectors; wavelength: 1310 nm; transmission distance: 10 km; OS1/OS2
    • Dual-mode twin-core fiber: Support LC optical connectors; wavelength: 850 nm; transmission distance: 300 m; OM3/OM4
  • The maximum loading capacity of a single optical port equals to that of all the 6 Ethernet
  • 2 OPT inputs/outputs
    • The OPT1 works as the primary input or output port, and the 6 Gigabit Ethernet ports work as the corresponding output or input
    • The OPT2 works as the backup input or output port of
  • In the sending card mode, both OPT ports and 6 Gigabit Ethernet ports can work as output ports to output the same

In the fiber converter construct mode, when the OPT ports work as the input ports, the 6 Gigabit Ethernet ports work as output ports. When the 6 Gigabit Ethernet ports work as input ports, the OPT ports work as output ports.





MONITOR





HDMI

Connect to a monitor to monitor the inputs. The output resolution of this connector is 1920×1080@60Hz (fixed output with a width of 1920 pixels and height of 1080 pixels).

If the input resolution exceeds the monitor resolution, the input will be automatically scaled in proportion and then displayed on the monitor starting from its top left.













Control





GENLOCK IN

GENLOCK input connector

  • Genlock type: Blackburst
  • Input Genlock sync signal to ensure synchronization and same refresh rate between the output signals of cascaded MCTRL660 PRO units and the external Genlock input signal.

GENLOCK LOOP

Genlock loop output connector. Up to 8 MCTRL660 PRO units can be cascaded.

ETHERNET

Fast Ethernet port, which connects to PC and supports TCP/IP

USB IN

Input port for cascading devices, or connecting to PC

USB OUT

Output port for cascading devices. Up to 8 MCTRL660 PRO units can be cascaded.

Power supply

100 V–240 V AC

Power switch

ON/OFF

Dimensions

Specifications



Electrical Parameters

Input voltage

100 V–240 V AC

Rated power consumption

20 W



Operating Environment

Temperature

-20°C–60°C

Humidity

10% RH–90% RH, non-condensing

Storage Environment

Temperature

-25°C–125°C













Packing Information



Carrying case

550 mm × 440 mm × 175 mm White cardboard box



Packing box

530 mm × 140 mm × 410 mm Craft paper box

Accessory box

White cardboard box







Accessories

1 × Ethernet cable 1 × DVI cable

1 × USB cable 1 × HDMI cable

1 × Power cord

Dimensions

482.6 mm × 356.0 mm × 50.1 mm

Space Requirement

1U

Net Weight

4.6 kg

Certifications

RoHS, EMC, FCC, IC, LVD
